Switches & Sensors for 2004 Suzuki Vitara

Switches & Sensors for 2004 Suzuki Vitara #0 Switches & Sensors for 2004 Suzuki Vitara #1
No.
Part # / Description / Price
Price
4
Upper Case
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: 1999-02. 2001-02, front.
5
Lower Case
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: 1999-02. 2001-02, front.
6
Packing
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: 1999-02, drain. 2001-02, front, drain.
7
Packing
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: Blower. 1999-02, inlet. 2001-02, front, inlet.
8
Packing
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: Dashboard. 1999-02, outlet. 2001-02, front, outlet.
9
Packing
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: Outlet. 1999-02, dashboard. 2001-02, front, dashboard.
11
Evaporator Core
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: Vitara. Denso.
12
Expansion Valve
Suzuki Suzuki
Notes: PARTS: Part included with evaporator core.
Description: Vitara. Denso. All.
13
Expansion Valve Bolt
Suzuki Suzuki
Notes: PARTS: Part included with evaporator core.
Description: Case & components.
14
Thermostatic Switch
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: Vitara. Denso. All.
15
Thermistor Clamp
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: 1999-02. 2001-02, front.
16
Cabin Air Filter
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: Vitara. Denso. All.
17
1999-2004 Suzuki - Filter Cover
Suzuki Suzuki
Notes: PARTS: Part included with evaporator assembly.
Description: THIS ITEM IS ON BACK ORDER
Switches & Sensors for 2004 Suzuki Vitara #1
No.
Part # / Description / Price
Price
1
Condenser
Suzuki Suzuki
Description: Vitara. Denso. All.
2
Condenser Insulator
Suzuki Suzuki
Positions: Left
Description: From vin 4105566 to 14155434. To vin 4105565.
2
Condenser Insulator
Suzuki Suzuki
Positions: Right
Description: From vin 4105566 to 14155434. To vin 4105565.
3
Condenser Bolt
Suzuki Suzuki
Description: From vin 14155435. 2001-02. 2003-06. From vin 4105566 to 14155434.
4
Condenser Assembly Bushing
Suzuki Suzuki
Description: From vin 14155435. Sedan. 2001-02. 2003-06. From vin 4105566 to 14155434.
6
Compressor
Suzuki Suzuki
Description: Vitara. 2.5l.
10
Clutch & Pulley
Suzuki Suzuki
Notes: PARTS: Part included with compressor.
Description: 2.5L.
11
Discharge Hose
Suzuki Suzuki
Description: Vitara. 2.5l.
12
Discharge Hose O-Ring
Suzuki Suzuki
Notes: PARTS: Part included with suction hose.
13
Suction Hose
Suzuki Suzuki
Description: Vitara. 2.5l.
13
Suction Hose
Suzuki Suzuki
Description: Grand Vitara. From vin 14155435. 2001-02. XL-7. Evaporator To Compressor.
16
Suction Pipe O-Ring
Suzuki Suzuki
Notes: PARTS: Part included with suction pipe.
17
Liquid Line
Suzuki Suzuki
Description: BACK ORDERED
17
Discharge Hose
Suzuki Suzuki
Description: Grand Vitara. Compressor To Condenser.
18
Liquid Line O-Ring
Suzuki Suzuki
Notes: PARTS: Part included with liquid line.
19
Pressure Switch
Suzuki Suzuki
Description: PART IS ON BACKORDER
20
A/C Receiver Drier
Suzuki Suzuki
Description: Vendor:denso.
